The SKIPPER IR300 is a remote speed repeater for NMEA0183 signals. It is designed for use with SKIPPER speed logs. It may also be used with speed logs from other manufacturers, when these have an NMEA 0183 output.
Description
Features
- Speed repeater
- Alarms - speed alarm
- Trip counter
- Distance counter
- One, two or three axis indication
- Bracket or panel mounting
Part number: |
|
| Power supply: | DC: 10-40 V |
| Power consumption: | 3 W at 24 VDC |
| Display: |
|
| Display output: |
|
| Cut-out dimensions: | 124x124 mm. bracket or panel mounting. Brackets included. |
| Front plate: | 144x144 mm to DIN standard |
| Depth: | 59 mm |
| Weight: | 1 kgs |
| IP rating: | 56 |
| Inputs: |
|
| Classifications: |
|
| Service: | Available in most major harbours, world-wide through extensive dealer network |
