CNFT VHF (Including Class-D DSC) Radio Equipment FT-805B
CNFT VHF (Including Class-D DSC) Radio Equipment FT-805B
1IncludesU.S., Canada,internationalchannelsand10 weather channels.Ithas dual-frequency and tri-frequencyon-duty,and70 channel (DSC )iscontinuouslyon-duty.Support selective call, groupcall
-
Includes U.S., Canada, international channels and 10 weather channels.
-
It has dual-frequency and tri-frequency on-duty, and 70 channel ( DSC ) is continuously on-duty.
-
Support selective call, group call, sea call, all call and other digital selective calls.
-
Distress call, confirmation, rebroadcast call.
-
Ship position request, ship position report.
-
FM ( 88-108MHz ) radio.
-
Automatically record DSC transmitted and incoming messages.
|
Frequency Range |
Tx： 156.025-157.425 MHz ，Rx： 156.025-163.275MHz |
Conducted spurious emissions transmitted to the antenna |
150 kHz~1 GHz：≤0.25 μW（-36 dBm） 1 GHz ~2 GHz：≤1 μW（-30 dBm） |
|
Modulation |
FM（16K0G3E）， DSC（26K0G2B） |
||
|
Frequency error |
≤±1.5 kHz |
Transmitter residual modulation |
≤-40 dB |
|
Operating Voltage |
DC13.8V(±15%) |
Rated audio output power |
≥2 W |
|
Antenna impedance |
50Ω |
Maximum usable sensitivity |
≤ +6 dB μV(e.m.f) |
|
Output impedance |
（Audio）8Ω |
Adjacent channel selectivity |
≥70 dB |
|
Input resistance |
（Microphone）2KΩ |
Spurious response suppression |
≥70 dB |
|
Frequency error |
≤±1.5 kHz |
Intermodulation response |
≥70 dB |
|
Carrier power |
25 W/1 W |
Block |
≥ +90 dBμV |
|
Maximum allowable frequency deviation |
≤±5 KHz |
Conducted spurious emissions transmitted to the antenna |
9 kHz～2 GHz：≤2 nW(-57 dBm) |
|
Harmonic distortion |
≤10% |
Receiver noise level |
≤-40 dB |
