Feature
-
Color large-screen electronic chart navigation, rich information display.
-
China's autonomous Beidou satellite navigation system, single Beidou positioning.
-
One-key alarm activation, support for distress alarm sending and receiving.
-
Voice, light, screen text multiple warning prompts.
-
List, radar chart, nautical chart, three target ship display modes.
-
Automatic storage of voyage data and surrounding ship dynamics.
Specifications
| AIS frequency band | 156.025～162.025MHz | Receiving sensitivity | -107dBm ，PER＜20% |
| Operating mode | CSTDMA | Error at high input level | -77dBm ，PER＜2%；-7dBm，PER＜10% |
| Operating temperature | -15℃~+55℃ | Transmitter spurious emission | ＜-36dBm（9KHz…1GHz）＜-30dBm（1GHz…4GHz） |
| Operating Voltage | DC12-24V | Positioning mode | Beidou |
| Waterproof level | IP45 | Receiving sensitivity | -133dBm (Tracking) ，-130dBm (Cold start） |
| LCD brightness | ≥500cd/m2 | First capture time | ≤15m |
| Transmit power | 33dBm±1.5dB | Positioning error | |
| Frequency error | ±500Hz |
