Feature
-
Using a microcomputer to control the synthesizer to ensure high frequency stability on each channel.
-
Up to 88 working channels.
-
Noise suppression, clear call.
-
External microphone speaker.
-
Friendly man-machine interface, easy to use by non-professionals.
-
Small and flexible, easy to identify in the dark.
-
Fully sealed and waterproof, strong adaptability to environment, long service life.
-
The battery can work continuously for more than 72 hours.
Specifications
|
Frequency Range |
Tx： 156.025-157.425MHz Rx： 156.050-163.275MHz |
Modulation limit |
≤±5KHz |
|
Transmitter spurious emissions |
≤0.25μW（150 kHz-1 GHz） ≤1μW（1 GHz-2 GHz） |
||
|
Frequency interval |
25kHz |
||
|
Modulation |
FM(16KOG3E) |
Transmitter's residual modulation |
≤-40dB |
|
Operating Voltage |
DC 6.4V |
Maximum usable sensitivity |
≤+6dBμV |
|
Operating temperature |
-15℃-55℃ |
Rated audio power |
Speaker：≥200mW，Earphone：≥1 mW |
|
Protection level |
IP67 |
Audio distortion |
≤7% |
|
Carrier power |
2W/1W |
Receiver spurious emission |
150 kHz~1 GHz≤-57dBm 1 GHz~2 GHz≤-37dBm |
|
Frequency error |
±1.5 KHz |
||
|
Modulation sensitivity |
20±10mV |
Signal-to-noise ratio |
≤-40 dB |
