Feature
-
Color large-screen electronic chart navigation, single-key single-use operation is simple.
-
Beidou / GPS dual mode positioning,improve positioning accuracy.
-
Voice, light, screen text multiple warning prompts.
-
List, radar chart, nautical chart, three target ship display modes.
-
One-key alarm activation, support for distress alarm sending and receiving Crew identity authentication function,
reserved second-generation ID card swiping interface.
-
Connect the mobile APP via WiFi to realize display control operation, SMS sending and receiving.
Specifications
AIS frequency band | 156.025～162.025MHz | Receiving sensitivity | -107dBm ，PER＜20% |
Operating mode | CSTDMA | Error at high input level | -77dBm ，PER＜2%；-7dBm ，PER＜10% |
Operating temperature | -15℃~+55℃ | Transmitter spurious emission | ＜-36dBm（9KHz…1GHz）＜-30dBm（1GHz…4GHz） |
Operating Voltage | DC12-24V | Positioning mode | Beidou+GPS |
Waterproof level | IP45 | Receiving sensitivity | -133dBm (tracking) ，-130dBm (cold start） |
LCD brightness | ≥500cd/m2 | First capture time | ≤120s |
Transmit power | 33dBm±1.5dB | Positioning error | ≤15m |
Frequency error | ±500Hz |
