CNFT Fixed Positioning Equipment For Small Fishing Boats FT-1600-D
CNFT Fixed Positioning Equipment For Small Fishing Boats FT-1600-D
1Fixedinstallation, with anti-disassembly and removalprotection measures, backgroundmonitoring.AIS/mobilepublicnetwork combination work to achieve full sea coverage.Built-in lithiumbattery +solarpower supply,un
Feature
-
Fixed installation, with anti-disassembly and removal protection measures, background monitoring.
-
AIS/ mobile public network combination work to achieve full sea coverage.
-
Built-in lithium battery + solar power supply, uninterrupted work.
-
Connect to mobile phone APP via WiFi to realize information display, navigation and other functions.
-
With one-key alarm, intelligent anti-collision alarm function.
-
Automatic report of ship dynamics and equipment operating status.
-
Automatically record own ship's track and surrounding AIS dynamic and static information.
Specifications
|
Public network frequency |
AIS private network+mobile public network |
Operating temperature |
-25℃~+55℃ |
|
AIS frequency band |
156.025～162.025MHz |
Waterproof level |
IP68 |
|
GNSS frequency |
1575.42MHz(GPS),1561.098MHz(Beidou) |
Transmit power |
33dBm±1.5dB |
|
Positioning error |
≤15m |
Frequency error |
±500Hz |
|
Operating mode |
CSTDMA |
Receiving sensitivity |
-107dBm ，PER＜20% |
|
Power supply |
Lithium battery + solar |
Error at high input level |
-77dBm ，PER＜2%；-7dBm ，PER＜10% |
|
Length of work |
>5 years （extreme no charging>3 months） |
Transmitter spurious emission |
＜-36dBm（9KHz…1GHz），＜-30dBm（1GHz…4GHz） |
