CNFT Portable (Class B) AIS Shipborne Equipment FT-1600
CNFT Portable (Class B) AIS Shipborne Equipment FT-1600
1Waterproof design, easy toinstall, easy to carry, easytooperate.Compatible with fishery AIS ( TypeB )systemandmaritime AIS(Type A) system.AIS /mobilepublicnetwork combination work to achieve
Feature
-
Waterproof design, easy to install, easy to carry, easy to operate.
-
Compatible with fishery AIS ( Type B ) system and maritime AIS ( Type A ) system.
-
AIS / mobile public network combination work to achieve full sea coverage.
-
With mobile phone APP software, providing navigation data display.
-
The ship's intelligent anti-collision alarm, the distance to the alarm can be set.
-
One-key distress alarm with protection measures against misoperation.
-
The warning light flashes and the voice broadcast prompt.
-
Automatically record own ship's track and surrounding AIS dynamic and static information.
-
Power-on self-inspection, timing power and positioning status detection, sound and light prompt of self-inspection results.
Specifications
|
Public network frequency |
850/900/1800/1900MHz |
Waterproof level |
IP67 |
|
AIS frequency band |
156.025～162.025MHz |
Transmit power |
33dBm±1.5dB |
|
GNSS frequency |
1575.42MHz(GPS),1561.098MHz(Beidou) |
Frequency error |
±500Hz |
|
Positioning error |
≤15m |
Receiving sensitivity |
-107dBm ，PER＜20% |
|
Operating mode |
CSTDMA Lithium battery DC7.2V |
Error at high input level |
-77dBm ，PER＜2% -7dBm ，PER＜10% |
|
Power supply |
|||
|
Continuous use time |
≥128h -30℃~+55℃ |
Transmitter spurious emission |
＜-36dBm（9KHz…1GHz） ＜-30dBm（1GHz…4GHz） |
