3M™ PROTECTA® Rebel™ Self-Retracting Lifeline - Cable 10m
3M™ PROTECTA® Rebel™ Self-Retracting Lifeline - Cable 10m
1Specifications
Anchor Connection Type | Swivel Snap Hook |
Anchor Hook Material | Zinc Plated Steel |
Brand | PROTECTA® |
Case Quantity | 1 |
Connected Safety ID Equipped | No |
Harness Connection Type | Carabiner |
Housing Material | Aluminum |
Housing Type | Metal |
Lifeline Hook Material | Zinc Plated Steel |
Lifeline Length (Imperial) | 33 ft |
Lifeline Length (Metric) | 10.1 m |
Lifeline Material | Galvanized Cable |
Material | Galvanized Cable |
Mounting Type | Overhead Anchor Point |
Overall Length (Imperial) | 33 ft |
Product Type | Self Retracting Lifeline - Cable |
Recommended Industry | Construction, General Industrial, Mining, Oil & Gas |
Specifications Met | ANSI A10.32, ANSI Z359.1, ANSI Z359.14, OSHA 1910.66, OSHA 1926.502 |
Weight (Imperial) | 16.8 lb. |
Weight Capacity | 420 lbs. (190 kg) |
Weight Capacity (Imperial) | 420 lb. |
Weight Capacity (Metric) | 190 kg |
Details
- Rugged aluminum housing
- Stackable housing design
- Built-in carrying handle
- 33 ft. (10m) 3/16" (5mm) galvanized steel cable lifeline
- Swiveling self-locking snap hook with impact indicator
- Speed sensing all metal brake system
- Internal energy absorption system
- Reserve lifeline system
- Side lifeline exit with ergonomic handle
- High strength, corrosion resistant components
- Swiveling anchorage point
- Self-locking anchorage carabiner
33 ft. (10m) of 3/16" (5mm) galvanized steel wire rope with swiveling snap hook, aluminum housing and anchorage carabiner. The Protecta® self retracting lifeline (SRL) line is built to last providing an economical fall protection solution without compromising performance or safety. Protecta® SRL’s feature a 420 pound (190 kg) user capacity, a robust design to ensure longevity and are available in lengths from 6 ft. (1.8m) to 100 ft. (30.5m). Available in either aluminum or composite housing models, these SRL’s are also equipped with an ergonomic carrying handle that makes transportation to and from the job site easy. Protecta® is designed with the worker in mind, featuring a stackable space maximizing design and an impact indicator to provide easy verification of whether the equipment has been involved in a fall. An SRL’s lifeline will extend as the user moves away, and retract automatically enabling the user to move about within a recommended working area at normal speeds. Should a fall occur, a speed sensing brake system will activate stopping the fall and reducing the forces imposed on the user to safe levels.
